MICRO30 - Laboratory effluent decontamination system

High-capacity electric thermal biowaste treatment with integrated energy recovery.

MICRO30 is an automated, electrically heated Effluent Decontamination System (EDS) designed for the thermal treatment of biologically contaminated liquid waste in laboratories, biotechnology facilities, and pilot-scale operations. With a treatment capacity of up to 790 gal/day (3,000 L/day), MICRO30 combines controlled batch thermal treatment, integrated heat recovery, and automated process monitoring in a compact system.

Its standard single-batch configuration treats up to 396 gal/day (1,500 L/day), while the optional double-batch configuration increases capacity to 790 gal/day (3,000 L/day). MICRO30 operates without an external steam supply or chilled water, helping simplify utility integration for facilities requiring higher treatment capacities.

Key specifications:

  • Capacity: Up to 396 gal/day (1,500 L/day) standard; 790 gal/day (3,000 L/day) with double batch
  • Technology: Electric batch EDS
  • Treatment: 275°F (135°C) for 2 minutes or 250°F (121°C) for 20 minutes
  • Thermal lethality: Adjustable F₀ from 20 to 50
  • Collection tank: 396 gal (1,500 L)
  • Energy recovery: Integrated, no chilled water required
Decontamination unit MICRO30

Why choose MICRO30 for laboratory biowaste treatment?

MICRO30 provides automated thermal decontamination for laboratories and biotechnology facilities requiring higher treatment capacities without relying on external steam or chilled water utilities.

High-capacity laboratory EDS

MICRO30 treats up to 396 gal/day (1,500 L/day) in its standard configuration. The optional double-batch configuration increases treatment capacity to 790 gal/day (3,000 L/day).

Fully electric operation

MICRO30 uses electric heating instead of direct steam injection, making it suitable for facilities without a centralized steam supply.

Integrated energy recovery

MICRO30 recovers thermal energy within its treatment process and eliminates the need for chilled water, helping reduce utility requirements.

Automated treatment cycles

MICRO30 automatically controls and monitors thermal treatment cycles, supporting repeatable operating conditions and reducing manual intervention.

Maintenance-friendly design

MICRO30 features pull-out equipment racks that improve access to internal components and facilitate routine maintenance operations.

MICRO30 technical specifications & benefits

Parameter

Specification

Benefits

Equipment MICRO30 High-capacity electric solution for laboratory biowaste treatment.
Application Laboratory and pilot-scale liquid biowaste decontamination Supports treatment of biological liquid waste from research and biotechnology activities.
Technology Batch thermal treatment Provides controlled, repeatable treatment cycles.
Heating method Electric No external steam supply required.
Maximum daily capacity - single batch 396 gal/day (1,500 L/day) Provides substantial treatment capacity in the standard configuration.
Maximum daily capacity - double batch 790 gal/day (3,000 L/day) Increases daily treatment capacity with an optional configuration.
Effluent characteristics Aqueous / water-like Designed for water-based biological liquid waste.
Collection tank capacity 396 gal (1,500 L) Collects biological liquid waste before treatment.
Optional external storage 260 gal (1,000 L) Provides additional liquid waste collection capacity.
Treatment vessel capacity 8 gal (30 L) Enables controlled thermal treatment in successive batches.
Treatment programs 275°F (135°C) for 2 min or 250°F (121°C) for 20 min Offers different thermal treatment conditions according to the application.
F₀ Adjustable 20–50 Allows configuration of the required thermal lethality target.
Electrical supply 480 V / 60 Hz / three-phase Specifies the industrial electrical connection required for installation.
Electrical power 11 kW Defines the installed electrical power requirement.
Energy recovery Integrated Recovers heat within the treatment process.
Cooling requirements No chilled water required Simplifies facility cooling utility requirements.
Control and monitoring Automated PLC control Supports repeatable treatment cycles and process monitoring.
Maintenance access Pull-out equipment racks Facilitates access to internal components for maintenance.
Standard dimensions (L × W × H) 56 × 80 × 87 in (1,410 × 2,020 × 2,200 mm) Provides defined dimensions for equipment layout and installation planning.

Maximum daily capacities depend on the selected configuration, treatment program, effluent characteristics, and operating conditions. The 790 gal/day (3,000 L/day) capacity requires the optional double-batch configuration.

How does the MICRO30 effluent decontamination system work?

MICRO30 uses automated batch thermal treatment with integrated energy recovery to process biologically contaminated liquid waste.

1. Liquid waste collection

MICRO30 collects biological liquid waste in its integrated 396 gal (1,500 L) collection tank before treatment.

An optional external storage tank can provide additional collection capacity according to facility requirements.

2. Automated electric heating

The system transfers effluent into its thermal treatment vessel and uses electric heating to reach the selected treatment temperature.

3. Controlled thermal treatment

MICRO30 maintains the required treatment temperature and holding time while monitoring operating parameters.

The system supports treatment programs at 275°F (135°C) for 2 minutes or 250°F (121°C) for 20 minutes, according to the selected configuration.

4. Energy recovery, cooling and discharge

MICRO30 uses integrated heat recovery to manage thermal energy during operation.

Following treatment and cooling, the system discharges the effluent through the designated outlet.

ACTINI defines treatment parameters and operating conditions according to the biological inactivation objectives, effluent characteristics, and facility requirements.

Tecnical schema

MICRO30 configuration and available options

Programme de traitement

Standard single-batch configuration

MICRO30 provides a treatment capacity of up to 396 gal/day (1,500 L/day) in its standard single-batch configuration.

Ajout - scalable - cuve

Optional double-batch configuration

The optional double-batch configuration increases maximum daily treatment capacity to 790 gal/day (3,000 L/day), accommodating facilities with higher liquid waste volumes.

Checklist

Optional external storage

ACTINI offers an optional external 260 gal (1,000 L) storage tank to provide additional waste collection capacity.

Energie electricité

Integrated energy recovery

MICRO30 incorporates heat recovery technology as part of its standard treatment process. The system operates without an external chilled water connection.

maintenance

Pull-out maintenance racks

MICRO30 includes pull-out equipment racks that improve access to components during inspection and maintenance.

Typical MICRO30 applications

MICRO30 is designed for laboratories, biotechnology facilities, and pilot-scale operations requiring automated thermal treatment of larger volumes of aqueous biological liquid waste.

Potential applications include:

  • Biotechnology research and development laboratories
  • Pharmaceutical and biopharmaceutical research facilities
  • Pilot-scale biological production facilities
  • Laboratories generating higher daily volumes of biological liquid waste
  • Facilities upgrading or expanding existing laboratory effluent treatment systems

ACTINI USA evaluates effluent composition, biological treatment requirements, daily waste volumes, available utilities, and installation constraints to confirm equipment suitability.

Decontamination unit MICRO30
Tecnical schema

Need a high-capacity electric laboratory EDS?

Whether you’re designing a new biotechnology facility, expanding laboratory operations, or upgrading an existing biological liquid waste treatment system, ACTINI USA helps you evaluate MICRO30’s suitability for your process.

Our engineering team supports equipment selection, utility integration, commissioning, and qualification activities according to your project requirements.

Frequently asked questions about MICRO30 (FAQ)

What is the maximum treatment capacity of MICRO30?

MICRO30 treats up to 396 gal/day (1,500 L/day) in its standard single-batch configuration.

The optional double-batch configuration increases capacity to 790 gal/day (3,000 L/day). Actual capacity depends on the treatment program and operating conditions.

Does MICRO30 require steam or chilled water?

No. MICRO30 uses electric heating and integrated energy recovery, eliminating the need for an external steam supply or chilled water connection.

The system requires a 480 V, 60 Hz, three-phase electrical supply.

What is the difference between MICRO10 and MICRO30?

Both MICRO10 and MICRO30 use automated electric batch thermal treatment with integrated heat recovery.

MICRO10 treats up to 80 gal/day (300 L/day), while MICRO30 reaches 396 gal/day (1,500 L/day) in its standard configuration or 790 gal/day (3,000 L/day) with the optional double-batch configuration.

MICRO30 also requires a three-phase electrical supply and offers maintenance access through pull-out equipment racks.

What treatment temperatures does MICRO30 use?

MICRO30 supports treatment programs at 275°F (135°C) for 2 minutes or 250°F (121°C) for 20 minutes.

ACTINI determines the appropriate treatment conditions according to the biological inactivation objectives and selected system configuration.

Can MICRO30 treat liquid waste containing solids or viscous materials?

MICRO30 is designed for aqueous, water-like biological liquid waste.

For effluents containing significant solids, particles, or viscous phases, ACTINI can evaluate alternative technologies such as DIRECTSTEAM or CYCLOBATCH / BDS.

Can MICRO30 increase treatment capacity as laboratory needs grow?

Yes. The optional double-batch configuration increases the maximum daily treatment capacity from 396 gal/day (1,500 L/day) to 790 gal/day (3,000 L/day).

ACTINI evaluates the required configuration during project engineering. Any modification to an installed system requires a separate technical feasibility assessment.

Tecnical schema
